How to reinstall firmware for ABB IRC5 FlexPendant
Sometimes when the firmware is corrupted or there is a fault with the circuit board, the FlexPendant gets stuck at the booting screen with no graphic or control but just a black screen. Before sending the FlexPendant to repair or purchasing a new one, one can try to force the FlexPendant to download and install…
-
How to set up Profinet connection between an ABB IRC5 controller and a Siemens PLC
ABB IRC5 controller can be set up as a basic IO device for a Siemens PLC over Profinet. The PLC then will act as a master, reading and writing various types of data to robot controller. To use Profinet communication for IRC5, the option 888-2 PROFINET Controller/Device must be purchased from ABB and installed. The…
-
How to create a new system in ABB S4C+ controller with RobInstall
The TCP/IPv4 properties of the Ethernet adapter of the used computer needs to be set as following. IP: 192.168.125.82 Subnet mask: 255.255.255.240 Default gateway: 192.168.125.81 Connect the computer Ethernet port to the service port on the front of the controller via a straight through cable. The creation of a new system requires either a backup…
-
How to activate/deactivate a mechanical unit within an ABB IRC5 robot controller
A mechanical unit can be either a robot, usually 4 or 6-axis, or an external axis, for example, a rotational tool holder or a linear slide. An IRC5 controller cabinet usually has a single drive unit to control up to 6 axes of a robot plus three additional drives. Its computer can be interfaced with…
-
How to setup communication between two PLCs via Siemens PN/PN coupler in TIA Portal
Two PLCs on separate networks can be setup to send/receive data via Profinet coupler such as one with part number 6ES7158-3AD10-0XA0 from Siemens. The device description file can be downloaded from support.industry.siemens.com. The GSD files then can be unzip into the following path in project folder. It is imported and installed into the project by…
-
How to upgrade project to higher version of TIA Portal.
It’s often confusing for new user to use the Migrate project.. option instead of upgrading a project. The Migrate project.. option is only for migrating program or project from a different Siemens environment other than TIA Portal. TIA Portal projects created by version V13 or higher can be automatically upgraded to a higher version by…
